Introduction:
AWS Import/Export is a service that accelerates transferring large amounts of data into and out of AWS using physical storage appliances, bypassing the Internet. AWS Import/Export supports transfers data directly onto and off of storage devices you own using the Amazon high-speed internal network.
Refer http://docs.aws.amazon.com/AWSImportExport/latest/DG/whatisdisk.html
Scenario 1: Take export dump on AWS database Server for some of the schemas.
Use following parfile to take export on aws database server
directory=<directory name>
dumpfile=<dumpfile name>
logfile=<logfile name>
schemas=<schema name>
compression=all
For example we are using AWSNSMP database to take schemas export and keep the dumpfile on database server
We need to use DATA_PUMP_DIR directory for keeping export dumpfile and logfiles.
SQL> select name,open_mode from v$database;
NAME OPEN_MODE
--------- --------------------
AWSNSMP READ WRITE
SQL> select * from dba_directories;
OWNER DIRECTORY_NAME DIRECTORY_PATH ORIGIN_CON_ID
---------- ------------------------ ------------------------------ -------------
SYS BDUMP /rdsdbdata/log/trace 0
SYS ADUMP /rdsdbdata/log/audit 0
SYS OPATCH_LOG_DIR /rdsdbbin/oracle/Opatch 0
SYS OPATCH_SCRIPT_DIR /rdsdbbin/oracle/Opatch 0
SYS DATA_PUMP_DIR /rdsdbdata/datapump 0
SYS OPATCH_INST_DIR /rdsdbbin/oracle/OPatch 0
6 rows selected.
1. Create Parfile and keep all parameters
vi AWSNSMP_WNL.par
directory=DATA_DUMP_DIR
dumpfile=bkp_AWSNSMP.dpdmp
logfile=bkp_AWSNSMP.log
schemas=STG_MTS_APP,STG_MTS_V,
STG_MTS,
STG_ENTRP_ADM2,
STG_ENTRP_ADM2_V,
STG_ENTRP_ADM2_RO,
STG_ENTRP_ADM2_APP,
STG_ENTRP_ADM1_APP,
STG_ENTRP_ADM1,
STG_ENTRP_ADM1_V,
STG_ENTRP_ADM1_RO,
STG_ENTRP_V,
STG_ENTRP_RO,
STG_ENTRP,
STG_ENTRP_APP
compression=all
2. Start export as follows.
$ expdp parfile=AWSNSMP_WNL.par
Export: Release 12.1.0.2.0 - Production on Wed Apr 26 02:28:27 2017
Copyright (c) 1982, 2014, Oracle and/or its affiliates. All rights reserved.
Username: system@AWSNSMP
Password:
3. Monitor the export log from Database.
Findout out file name by querying RDSADMIN.RDS_FILE_UTIL.LISTDIR package from Database.
SQL> select * from table(RDSADMIN.RDS_FILE_UTIL.LISTDIR('DATA_PUMP_DIR')) order by mtime;
FILENAME TYPE FILESIZE MTIME
---------------------------------------- ---------- ---------- ---------
bkp_AWSNSMP.dpdmp file 3051520 18-APR-17
bkp_AWSNSMP.log file 12118 18-APR-17
datapump/ directory 4096 18-APR-17
use following package to view the import logfile.
SQL> select * from table
(rdsadmin.rds_file_util.read_text_file(
p_directory => 'DATA_PUMP_DIR',
p_filename => 'datapump/bkp_AWSNSMP.log')); 2 3 4
TEXT
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
;;;
Export: Release 12.1.0.2.0 - Production on Tue Apr 18 10:16:29 2017
Copyright (c) 1982, 2014, Oracle and/or its affiliates. All rights reserved.
;;;
Connected to: Oracle Database 12c Enterprise Edition Release 12.1.0.2.0 - 64bit Production
With the Partitioning, OLAP, Advanced Analytics and Real Application Testing options
Starting "SYSTEM"."SYS_EXPORT_SCHEMA_01": SYSTEM/********@AWSNSMP directory=DATA_PUMP_DIR dumpfile=bkp_AWSNSMP.dpdmp logfile=bkp_AWSNSMP.log schemas=STG_MTS_APP,STG_MTS_V,STG_
MTS,STG_ENTRP_ADM2,STG_ENTRP_ADM2_V,STG_ENTRP_ADM2_RO,STG_ENTRP_ADM2_APP,STG_ENTRP_ADM1_APP,STG_ENTRP_ADM1,STG_ENTRP_ADM1_V,STG_ENTRP_ADM1_RO,STG_ENTRP_V,STG_ENTRP_RO,STG_ENTRP,STG_ENTRP_APP compression=all encryption_password=********
Estimate in progress using BLOCKS method...
Processing object type SCHEMA_EXPORT/TABLE/TABLE_DATA
Total estimation using BLOCKS method: 28.62 MB
Processing object type SCHEMA_EXPORT/USER
Processing object type SCHEMA_EXPORT/SYSTEM_GRANT
. . exported "STG_ENTRP_ADM2"."RECORD_SEQ_POSITION" 0 KB 0 rows
. . exported "STG_ENTRP_ADM2"."REVINFO" 0 KB 0 rows
. . exported "STG_ENTRP_ADM2"."SCHEDULED_FORM" 0 KB 0 rows
. . exported "STG_ENTRP_ADM2"."SIGNATURE" 0 KB 0 rows
. . exported "STG_ENTRP_ADM2"."SIGNATURE_AUD" 0 KB 0 rows
. . exported "STG_MTS"."MTS_DEPLOYMENT" 0 KB 0 rows
Master table "SYSTEM"."SYS_EXPORT_SCHEMA_01" successfully loaded/unloaded
******************************************************************************
Dump file set for SYSTEM.SYS_EXPORT_SCHEMA_01 is:
/rdsdbdata/datapump/bkp_AWSNSMP.dpdmp
Job "SYSTEM"."SYS_EXPORT_SCHEMA_01" successfully completed at Tue Apr 18 14:16:51 2017 elapsed 0 00:00:16
Scenario 2: Perform export on local server from AWS database.
Connect to any local database server.
1. Create directory to accommodate dumpfile and logfile.
SQL> select * from dba_directories where directory_name like '%AWS%';
OWNER DIRECTORY_NAME DIRECTORY_PATH ORIGIN_CON_ID
---------- -------------------- -------------------------------------- -------------
SYS AWS_PUMP_DIR /mounts/nsgpr01_exports/exp/AWS 0
2. Create database link.
SQL> CREATE DATABASE LINK AWSNSMP_SYSTEM_LINK CONNECT TO SYSTEM IDENTIFIED BY <password> USING 'AWSNSMP';
Database link created.
3. Create parfile and include network link parameter and encryption option.
Vi AWSNSMP_NL.par
directory=AWS_PUMP_DIR
dumpfile=bkp_AWSNSMP.dpdmp
logfile=bkp_AWSNSMP.log
schemas=STG_MTS_APP,
STG_MTS_V,
STG_MTS,
STG_ENTRP_ADM2,
STG_ENTRP_ADM2_V,
STG_ENTRP_ADM2_RO,
STG_ENTRP_ADM2_APP,
STG_ENTRP_ADM1_APP,
STG_ENTRP_ADM1,
STG_ENTRP_ADM1_V,
STG_ENTRP_ADM1_RO,
STG_ENTRP_V,
STG_ENTRP_RO,
STG_ENTRP,
STG_ENTRP_APP
compression=all
NETWORK_LINK=AWSNSMP_SYSTEM_LINK encryption_password=*******
4. Initiate export.
$ expdp parfile=AWSNSMP_NL.par
Export: Release 12.1.0.2.0 - Production on Wed Apr 26 03:10:15 2017
Copyright (c) 1982, 2014, Oracle and/or its affiliates. All rights reserved.
Username:system
Password
5. Monitor export log
$ tail -f bkp_AWSNSMP.log
;;;
Export: Release 12.1.0.2.0 - Production on Tue Apr 18 10:12:00 2017
Copyright (c) 1982, 2014, Oracle and/or its affiliates. All rights reserved.
;;;
Connected to: Oracle Database 12c Enterprise Edition Release 12.1.0.2.0 - 64bit Production
With the Partitioning, OLAP, Advanced Analytics and Real Application Testing options
Starting "SYS"."SYS_EXPORT_SCHEMA_01": /******** AS SYSDBA parfile=AWSNSMP_NL.par
Estimate in progress using BLOCKS method...
Processing object type SCHEMA_EXPORT/TABLE/TABLE_DATA
Total estimation using BLOCKS method: 17.62 MB
Processing object type SCHEMA_EXPORT/USER
Processing object type SCHEMA_EXPORT/SYSTEM_GRANT
Processing object type SCHEMA_EXPORT/ROLE_GRANT
Processing object type SCHEMA_EXPORT/DEFAULT_ROLE
Processing object type SCHEMA_EXPORT/PRE_SCHEMA/PROCACT_SCHEMA
. . exported "STG_ENTRP_ADM2"."REVINFO" 0 KB 0 rows
. . exported "STG_ENTRP_ADM2"."SCHEDULED_FORM" 0 KB 0 rows
. . exported "STG_ENTRP_ADM2"."SIGNATURE" 0 KB 0 rows
. . exported "STG_ENTRP_ADM2"."SIGNATURE_AUD" 0 KB 0 rows
. . exported "STG_MTS"."MTS_DEPLOYMENT" 0 KB 0 rows
Master table "SYS"."SYS_EXPORT_SCHEMA_01" successfully loaded/unloaded
******************************************************************************
Dump file set for SYS.SYS_EXPORT_SCHEMA_01 is:
/mounts/nsgpr01_exports/exp/AWS/bkp_AWSNSMP.dpdmp
Job "SYS"."SYS_EXPORT_SCHEMA_01" successfully completed at Tue Apr 18 10:14:21 2017 elapsed 0 00:02:18
Scenario 3: Perform data load into AWS database using import.
1. Create database link on local server to communicate with aws database.
SQL>CREATE DATABASE LINK AWSNSTN_SYSTEM_LINK CONNECT TO SYSTEM IDENTIFIED BY ***** USING 'AWSNSTN';
Database link created.
2. Transfer the dumpfile into aws database server:
Refer below link for transfer file to AWS.
http://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/Oracle.Procedural.Importing.html
Use the following DBMS_FILE_TRANSFER.PUT_FILE to transfer file to aws Database server.
set timing on
set time on
BEGIN
DBMS_FILE_TRANSFER.PUT_FILE (
source_directory_object => 'AWS_PUMP_DIR',
source_file_name => 'expdp_NSMPAC_schema.dmp',
destination_directory_object => 'DATA_PUMP_DIR',
destination_file_name => 'expdp_NSMPAC_schema.dmp',
destination_database => 'AWSNSTN_SYSTEM_LINK');
END;
/
Source_directory_object --> local database directory where your dumpfile located
Source_file_name --> Dumpfile name
destination_directory_object --> aws database directory where you need to place the dumpfile
destination_database --> Database link
3. Monitor transfer of files from database.
Issue following query to view the filename
select * from table(RDSADMIN.RDS_FILE_UTIL.LISTDIR('DATA_PUMP_DIR')) order by mtime;
$ sqlplus
SQL*Plus: Release 12.1.0.2.0 Production on Wed May 3 01:02:25 2017
Copyright (c) 1982, 2014, Oracle. All rights reserved.
Enter user-name: SYSTEM@AWSNSTN
Enter password:
Last Successful login time: Tue May 02 2017 01:13:16 -04:00
Connected to:
Oracle Database 12c Enterprise Edition Release 12.1.0.2.0 - 64bit Production
With the Partitioning, OLAP, Advanced Analytics and Real Application Testing options
SQL> select name,open_mode from v$database;
NAME OPEN_MODE
--------- --------------------
AWSNSTN READ WRITE
SQL> select * from table(RDSADMIN.RDS_FILE_UTIL.LISTDIR('DATA_PUMP_DIR')) order by mtime;
FILENAME TYPE FILESIZE MTIME
-------------------------------------------------- ---------- ---------- ------------------
expdp_NSMPAC_schema.dmp file 2.0437E+10 18-APR-17
impdp_NSMPAC_schema.log file 164046 18-APR-17
datapump/ directory 4096 19-APR-17
4. create parfile for import with parallel parameter to speed up the import process.
vi impdp_AWSNSTN_schemas.ctl
directory=DATA_PUMP_DIR dumpfile=expdp_NSMPAC_schema.dmp logfile=impdp_NSMPAC_schema.log schemas=BRMGR01 transform=oid:n parallel=16
5. Start import in nohup and background
nohup impdp SYSTEM/*****@AWSNSTN parfile=impdp_AWSNSTN_schemas.ctl &
6. Monitor import log from database.
SQL> select * from table(RDSADMIN.RDS_FILE_UTIL.LISTDIR('DATA_PUMP_DIR')) order by mtime;
FILENAME TYPE FILESIZE MTIME
-------------------------------------------------- ---------- ---------- ------------------
expdp_NSMPAC_schema.dmp file 2.0437E+10 18-APR-17
impdp_NSMPAC_schema.log file 164046 18-APR-17
datapump/ directory 4096 19-APR-17
From above results you have file names,
Use rdsadmin.rds_file_util.read_text_file to read import logfile
SQL> select * from table
(rdsadmin.rds_file_util.read_text_file(
p_directory => 'DATA_PUMP_DIR',
p_filename => 'datapump/impdp_NSMPAC_schema.log')); 2 3 4
TEXT
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
;;;
Import: Release 12.1.0.2.0 - Production on Tue Apr 18 13:07:42 2017
Copyright (c) 1982, 2014, Oracle and/or its affiliates. All rights reserved.
;;;
Connected to: Oracle Database 12c Enterprise Edition Release 12.1.0.2.0 - 64bit Production
With the Partitioning, OLAP, Advanced Analytics and Real Application Testing options
Master table "SYSTEM"."SYS_IMPORT_SCHEMA_01" successfully loaded/unloaded
Starting "SYSTEM"."SYS_IMPORT_SCHEMA_01": SYSTEM/********@AWSNSTN parfile=impdp_AWSNSTN_schemas.ctl
Processing object type SCHEMA_EXPORT/USER
Processing object type SCHEMA_EXPORT/PROCEDURE/PROCEDURE
Processing object type SCHEMA_EXPORT/PROCEDURE/AUDIT_OBJ
Processing object type SCHEMA_EXPORT/PACKAGE/COMPILE_PACKAGE/PACKAGE_SPEC/ALTER_PACKAGE_SPEC
Processing object type SCHEMA_EXPORT/FUNCTION/ALTER_FUNCTION
Processing object type SCHEMA_EXPORT/PROCEDURE/ALTER_PROCEDURE
Processing object type SCHEMA_EXPORT/TABLE/INDEX/INDEX
Processing object type SCHEMA_EXPORT/TABLE/INDEX/FUNCTIONAL_INDEX/INDEX
Processing object type SCHEMA_EXPORT/TABLE/CONSTRAINT/CONSTRAINT
Processing object type SCHEMA_EXPORT/TABLE/INDEX/STATISTICS/INDEX_STATISTICS
Processing object type SCHEMA_EXPORT/TABLE/INDEX/STATISTICS/FUNCTIONAL_INDEX/INDEX_STATISTICS
Job "SYSTEM"."SYS_IMPORT_SCHEMA_01" completed at Tue Apr 18 19:46:36 2017 elapsed 0 02:38:50
2462 rows selected.
Conclusion:
In this preceding scenario based article we have learned how to perform export from aws databases and import into aws databases from on-premises to AWS and vice versa.
